LBC1400/10
Volume control with override relay, power-save, 12W
12 W max | 5 x 3 dB + off | 24 VDC override relay | Power-save | White RAL 9010
LBC1400/10
Volume control with override relay, power-save, 12W
12 W max | 5 x 3 dB + off | 24 VDC override relay | Power-save | White RAL 9010
Bosch LBC1400/10 Product Highlights
Explore the key capabilities of the Bosch LBC1400/10 volume control.
12 W Load
Controls up to 12 W of loudspeakers on a 100 V line.
5 x 3 dB + off
5 x 3 dB + off with a continuously rotating knob.
Emergency Override
A 24 VDC relay overrides the local setting for emergency calls.
Power-save
The relay is powered only during an emergency call.
3-Wire or 4-Wire
Suits 3-wire and 4-wire override systems.
Optional Surface Box
Add the LM1-SMB-MK box for surface mounting (ask us).
Key specs
- Max load 12 W, 100 V
- 5 x 3 dB + off
- 24 VDC override relay, 20 mA
- Power-save version
- Continuous rotating knob
- 87 x 87 x 45.6 mm
- Screw connections
- White RAL 9010
- EN 60065, UL 94 V0
Know before you buy
Quick answers about the LBC1400/10 12W Power-save, and how it compares.
How does the volume control work in an emergency?
Each Bosch volume control has a built-in 24 VDC override relay. In an emergency call the system switches the relay, so the message plays at the preset level whatever the local volume setting (4-wire override).
- /10, power-save: the relay is activated during the emergency call.
- /20, failsafe: the relay is deactivated during the emergency call.
The relay draws 20 mA at 24 VDC.
Which volume control do I need?
| Model | Max load | Steps | Version | Size |
|---|---|---|---|---|
| LBC1400/10 | 12 W | 5 x 3 dB + off | Power-save | 87 x 87 mm |
| LBC1400/20 | 12 W | 5 x 3 dB + off | Failsafe | 87 x 87 mm |
| LBC1410/10 | 36 W | 8 x 3 dB + off | Power-save | 87 x 87 mm |
| LBC1420/10 | 100 W | 10 x 2 dB + off | Power-save | 87 x 147 mm, surface box included |
| LBC1420/20 | 100 W | 10 x 2 dB + off | Failsafe | 87 x 147 mm, surface box included |
Add up the power taps of the loudspeakers on the control; the total must not exceed its maximum load. The LM1-SMB-MK surface box (ask us) fits the LBC1400 and LBC1410.
What do the power taps mean?
Each loudspeaker can be set to one of its power taps, for example 6 / 3 W. Choose a lower tap for small or quiet areas and a higher tap for large or noisy ones. Add up the taps of every loudspeaker on a line: the amplifier must deliver at least that total.
Many 6 W ceiling loudspeakers are tapped down to 3 W, 1.5 W or 0.75 W in the field; in smaller or low-noise areas 3 W is more than enough.
