LP1-UC10E-1

Bosch LP1-UC10E-1 10W Sound projector, unidirectional, white ABS enclosure with metal grilles, Sound pressure level: at 10 W / 1 W (1kHz, 1 m): 96 dB / 86 dB (SPL), Opening angle at 1 kHz / 4 kHz (-6 dB): 220° / 65°, Effective frequency range (-10dB): 75 Hz to 20 kHz, water and dust protected, IP65, EN54-24 certified, white RAL 9010.

https://www.esco.pk/web/image/product.template/24077/image_1920?unique=92c4e1c

    Rs. 0.00 0.0 PKR Rs. 0.00

    Not Available For Sale

    This combination does not exist.

    Add to Cart
    Add to wishlist Compare
    Contact Us
    Bosch

    Is our price higher than expected or showing as zero? Chat with us now for the best price and product availability. Prices if shown are inclusive of applicable taxes. Tax rate may be adjusted as per customer's taxation status. For supply of product only, excluding any cabling and/or installation. Shipping charges can sometimes vary.

    ​

    Loudspeaker Type

    Bosch LP1-UC10E-1 10W Sound projector

    Opening Angle

    Opening angle at 1 kHz / 4 kHz (-6 dB): 220° / 65°

    Applications

    High quality speech and music reproduction in indoor and outdoor applications. The

    state‑of‑the‑art design is matched to both modern and traditional style environments.

    Effective Frequency Range

    75 Hz to 20 kHz

    Power

    Rated power 10 / 5 / 2.5 W

    Sound Pressure Level

    Sound pressure level at 10 W / 1 W (1kHz, 1 m): 96 dB / 86 dB (SPL)

    Sound pressure level at 10 W /1 W (1kHz, 4 m): 88 dB / 78 dB (SPL)

    Electrical

    Rated power

    10 / 5 / 2.5 W

    Sound pressure level

    at 10 W / 1 W (1kHz, 1 m)

    96 dB / 86 dB (SPL)

    Sound pressure level

    at 10 W /1 W (1kHz, 4 m)

    88 dB / 78 dB (SPL)

    Opening angle

    at 1 kHz / 4 kHz (-6 dB)

    220° / 65°

    Effective frequency range (-10 dB)

    75 Hz to 20 kHz

    Rated voltage Rated impedance

    100 V

    10 W: 1000 Ohm

    5 W: 2000 Ohm

    2.5 W: 4000 Ohm

    1.25 W: 4000 Ohm

    Connector

    3-pole screw terminal

    Mechanical

    Dimensions (D x L)

    185 x 300 mm (7.3 x 11.8 in.)

    Weight

    3 kg (6.6 lb)

    Color

    White (RAL 9010)

    Material

    ABS

    Environmental



    Operating temperature

    -25 ºC to +55 ºC

    (-13 ºF to +131 ºF)

    Storage and transport temperature

    -40 ºC to +70 ºC

    (-40 ºF to +158 ºF)

    Relative humidity

    <95%
