PRA-APAS

Bosch PRA-APAS Advanced Public Address Server, Server for the advanced public address software license, Interface for third party PCs and tablet devices to the PRAESENSA IP‑network, IP‑networked on existing Local Area Networks, Secure internet connection to the Local Area, Network (LAN) of the building, internet radio, online music streaming and text‑to‑speech‑service, Internal memory for business messages library and music playlists.

https://www.esco.pk/web/image/product.template/24034/image_1920?unique=8ed642d

    Rs. 0.00 0.0 PKR Rs. 0.00

    Not Available For Sale

    This combination does not exist.

    Add to Cart
    Add to wishlist Compare

    Please get in touch for pricing & availability.

    Contact Us
    Bosch

    Is our price higher than expected or showing as zero? Chat with us now for the best price and product availability. Prices if shown are inclusive of applicable taxes. Tax rate may be adjusted as per customer's taxation status. For supply of product only, excluding any cabling and/or installation. Shipping charges can sometimes vary.

    ​

    Electrical

    Server PC

    Model

    ARK‑1124H‑S6A1E (OEM Advantech)

    Processor chipset

    Intel Atom™ E3940 Quad Core SoC

    Processor speed

    1.6 GHz

    L2 Cache

    2 MB

    BIOS

    AMI EFI 64 bit

    Memory

    DDR3L 1866 MHz, 8 GB

    Operating system

    Linux

    Graphics chipset

    Intel ® HD Graphics 500

    Video interface

    HDMI 1.4b, dual display

    Ethernet chipset

    Intel i210 GbE

    LAN1/2

    100BASE TX, 1000BASE T

    Audio chipset

    Realtek ALC888S,

    Audio in/out (inactive)

    2 x analog mini‑jack

    Serial interface

    RS-232/422/485

    USB Interface

    4 x USB 3.0

    Protection

    Watchdog timer

    Backup battery

    CR2032 Lithium cell

    Power consumption, typical

    6 W

    Power consumption, maximum

    16 W

    External power adapter

    12 VDC, 5 A

    Power connector

    Lockable DC jack

    Cooling

    Fanless convection

    Power adapter

    Input voltage range

    100 — 240 VAC

    Input voltage tolerance

    90 — 264 VAC

    Frequency range

    47 — 63 Hz

    Socket type input

    C14

    Output voltage

    12 VDC

    Connector type output

    5A

    Efficiency Level (DOE)

    Lockable DC jack

    Protection

    Over voltage

    Over current

    Over temperature

    Mechanical

    Enclosure server PC

    Dimensions (HxWxD)

    46.4 x 133 x 94.2 mm

    (1.83 x 5.24 x 3.71 in)

    Case

    Material Color



    Aluminum Black

    Weight

    0.7 kg (1.55 lb)

    Enclosure power adapter

    Dimensions (W x H x D)

    110 x 62 x 31.5 mm

    (4.33 x 2.44 x 1.24 in)

    Environmental

    Climatic conditions server PC

    Operating temperature

    -20 — 60 ºC

    (-4 — 140 ºF)

    with 0.7 m/s air flow

    Storage and transport temperature

    -40 — 85 ºC

    (-40 — 185 ºF)

    Humidity (non‑condensing)

    5 — 95%

    Climatic conditions server PC

    Vibration (operating, no HDD)

    3 Grms, IEC 60068‑2‑64,

    random, 5 to 500 Hz, 1 hr/ axis

    Shock (operating, no HDD)

    30 G, IEC 60068‑2‑27, half

    sine, 11 ms duration

    Climatic conditions power adapter

    Operating temperature

    0 ºC — 40 ºC

    (32 ºF — 104 ºF)

    Storage and transport temperature

    -30 ºC — 60 ºC

    (-22 ºF — 140 ºF)

    Altitude

    -500 — 5000 m

    (-1640 — 16404 ft)
