Camera
|
Sensor
|
1/1.2"
Progressive Scan CMOS
|
Min.
Illumination
|
Color:
0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light
|
Max.
Resolution
|
3840
× 2160
|
Shutter
Speed
|
1/3
s to 1/100,000 s
|
P/N
|
P/N
|
Wide
Dynamic Range
|
130
dB
|
Angle
Adjustment
|
Pan:
0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
|
Lens
|
Lens
Type & FOV
|
4
mm: horizontal FOV 88°, vertical FOV 47°, diagonal FOV 104°
|
Depth
of Focus
|
4
mm: 7 m to ∞
|
Aperture
|
F1.0
|
DORI
|
DORI
|
4
mm, D: 102 m, O: 41 m, R: 21 m, I: 11 m
|
Illuminator
|
White
Light Range
|
40 m
|
Smart
Supplement Light
|
Yes
|
Video
|
Main
Stream
|
50 Hz:
25 fps
(3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
24 fps
(3840 × 2160)
30 fps
(3200 x 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
|
Sub
Stream
|
50 Hz:
25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz:
30 fps (1280 × 720, 640 × 480, 640 × 360)
|
Third
Stream
|
50 Hz:
10 fps (1920 x 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz:
10 fps (1920 x 1080, 1280 × 720, 640 × 480, 640 × 360)
|
Video
Compression
|
Main
stream: H.265 / H.264 / H.264+ / H.265+
Sub-stream:
H.265 / H.264 / MJPEG
Third
stream: H.265 / H.264
|
Video
Bit Rate
|
32 Kbps
to 16 Mbps
|
H.264
Type
|
Baseline
Profile / Main Profile / High Profile
|
H.265
Type
|
Main
Profile
|
Bit
Rate Control
|
CBR/VBR
|
Scalable
Video Coding (SVC)
|
Yes
|
Region
of Interest (ROI)
|
1 fixed
region for main stream and sub-stream
|
Audio
|
Audio
Compression
|
-U:
G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
|
Audio
Bit Rate
|
-U:
64 Kbps (G.711 ulaw) / 64 Kbps(G.711 alaw) / 16 Kbps(G.722.1) / 16 Kbps(G.726)
/ 32 to 192 Kbps(MP2L2) / 8 to 320 Kbps(MP3) / 16 to 64Kbps (AAC-LC)
|
Audio
Sampling Rate
|
-U:
8 kHz / 16 kHz / 32 kHz / 44.1 kHz / 48 kHz
|
Environment
Noise Filtering
|
-U:
Yes
|
Network
|
Simultaneous
Live View
|
Up to
6 channels
|
API
|
Open
Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X,
QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
|
User/Host
|
Up to
32 users. 3 user levels: administrator, operator and user
|
Security
|
Password
protection, complicated password, HTTPS encryption, IP address filter, Security
Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE
and digest authentication for Open Network Video Interface
|
Network
Storage
|
NAS
(NFS, SMB/CIFS), auto network replenishment (ANR)
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
Enhancement
|
BLC,
HLC, 3D DNR
|
Parameters Switch
|
Yes
|
Settings
|
Rotate,
mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white
balance adjustable by client software or web browser
|
Interface
|
Built-in
Microphone
|
-U:
Yes
|
On-board
Storage
|
Built-in
memory card slot, support microSD / microSDHC / microSDXC / TF card, up to 512
GB
|
Hardware
Reset
|
Yes
|
Communication
Interface
|
1 RJ45
10 M/100 M self-adaptive Ethernet port
|
Event
|
Basic
Event
|
Motion
detection (human and vehicle targets classification), video tampering alarm, exception
(network disconnected, IP address conflict, illegal login, HDD full, HDD error)
|
Smart
Event
|
Scene
change detection
|
Linkage
|
Upload
to FTP/memory card/NAS, notify surveillance center, trigger record, trigger capture,
send email
|
Deep Learning Function
|
Face
Capture
|
Yes
|
Perimeter
Protection
|
Line
crossing, intrusion, region entrance, region exiting
Supports human and vehicle targets classification
|
General
|
Power
|
12 VDC
± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE:
(802.3af, Class 3, 36 V to 57 V), 0.25 A to 0.15 A, max. 7.5 W
|
General
Function
|
Anti-flicker,
heartbeat, password reset via e-mail, pixel counter
|
Software
Reset
|
Yes
|
Storage
Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
Startup
and Operating Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
Material
|
Front
cover: metal, back cover: metal
|
Camera
Dimension
|
78.8
× 78.6 × 215.2 mm (3.1" × 3.1" × 8.5'')
|
Package
Dimension
|
315
× 137 × 141 mm (12.4" × 5.4" × 5.6")
|
Camera
Weight
|
Approx.
850 g (1.9 lb.)
|
With
Package Weight
|
Approx.
1270 g (2.8 lb.)
|
Approval
|
EMC
|
FCC
(47 CFR Part 15, Subpart B);
CE-EMC
(EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN
50130-4:
2011 +A1: 2014);
RCM
(AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7)
|
Safety
|
UL (UL
62368-1);
CB (IEC
62368-1:2014+A11)
CE-LVD
(EN 62368-1:2014/A11:2017)
|
Environment
|
CE-RoHS
(2011/65/EU); WEEE (2012/19/EU);
Reach
(Regulation (EC) No 1907/2006)
|
Protection
|
IP67
(IEC 60529-2013)
|
