Camera
|
|
Sensor
|
1/2.5"
Progressive Scan CMOS
|
|
Min.
Illumination
|
Color:
0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR
|
|
Shutter
Speed
|
1/3
s to 1/100,000 s
|
|
Slow
Shutter
|
Yes
|
|
P/N
|
P/N
|
|
Wide
Dynamic Range
|
120
dB
|
|
Day
& Night
|
IR cut
filter
|
|
Angle
Adjustment
|
Pan:
0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
|
|
Lens
|
|
Lens
Type & FOV
|
4 mm,
horizontal FOV 83°, vertical FOV 44°, diagonal FOV 98°
|
|
Aperture
|
F2.0
|
|
Lens
Mount
|
M12
|
|
Illuminator
|
|
IR
Range
|
Up to
30 m
|
|
Wavelength
|
850
nm
|
|
Smart
Supplement Light
|
Yes
|
|
Video
|
|
Max.
Resolution
|
3840
× 2160
|
|
Main
Stream
|
50 Hz:
12.5 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz:
15 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 720)
|
|
Sub
Stream
|
50 Hz:
25 fps (640 × 480, 640 × 360)
60 Hz:
30 fps (640 × 480, 640 × 360)
|
|
Video
Compression
|
Main
stream: H.265+/H.265
Sub-stream:
H.265/MJPEG
|
|
Video
Bit Rate
|
32 Kbps
to 16 Mbps
|
|
H.265
Type
|
Main
Profile
|
|
H.265+
|
Main
stream supports
|
|
Bit
Rate Control
|
CBR/VBR
|
|
Scalable
Video Coding (SVC)
|
H.265
supports
|
|
Region
of Interest (ROI)
|
1 fixed
region for main stream and sub-stream
|
|
Audio
|
|
Environment
Noise Filtering
|
Yes
|
|
Audio
Sampling Rate
|
8 kHz/16
kHz
|
|
Audio
Compression
|
G.711ulaw
/ G.711alaw / G.722.1 / G.726 / MP2L2 / PCM/AAC
|
|
Audio
Bit Rate
|
64 Kbps
(G.711) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 to 160 Kbps (MP2L2) / 16 to
64 Kbps (AAC)
|
|
Network
|
|
Simultaneous
Live View
|
Up to
6 channels
|
|
API
|
Open
Network Video Interface (PROFILE S, PROFILE G), ISAPI, SDK, ISUP
|
|
Protocols
|
TCP/IP,
ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS,
Bonjour, FTP, SMTP, 802.1x, SSL/TLS, PPPoE
|
|
User/Host
|
Up to
32 users
3 levels:
Administrator, Operator and User
|
|
Network
Storage
|
Supports
microSD / SDHC / SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto
network replenishment (ANR)
|
|
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
|
Enhancement
|
BLC,
HLC, 3D DNR
|
|
Settings
|
Mirror,
saturation, brightness, contrast, sharpness, AGC, and white balance adjustable
by client software or web browser
|
|
Privacy
Mask
|
4 regions
of privacy masks
|
|
Interface
|
|
Built-in
Microphone
|
Yes
|
|
On-board
Storage
|
Built-in
microSD / SDHC / SDXC slot, up to 256 GB
|
|
Hardware
Reset
|
Yes
|
|
Communication
Interface
|
1 RJ45
10 M/100 M self-adaptive Ethernet port
|
|
Smart Feature-Set
|
|
Basic
Event
|
Motion
detection, video tampering, exception
|
|
General
|
|
Linkage
Method
|
Upload
to FTP / NAS / memory card, notify surveillance center, send email, trigger recording,
trigger capture
|
|
General
Function
|
Anti-flicker,
heartbeat, password protection, password reset via email
|
|
Software
Reset
|
Yes
|
|
Storage
Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Startup
and Operating Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Power
Supply
|
12 VDC
± 25%
PoE:
802.3af, Type 1 Class 3
|
|
Power
Consumption and Current
|
12 VDC,
0.4 A, max. 5 W
PoE
(802.3af, 36 V to 57 V), 0.20 A to 0.15 A, max. 6.5 W
|
|
Power
Interface
|
Ø5.5
mm coaxial power plug
|
|
Camera
Material
|
Aluminum
alloy body
|
|
Camera
Dimension
|
171.4
mm × 69.7 mm × 67.9 mm (6.7" × 2.7" × 2.7")
|
|
Package
Dimension
|
216
mm × 121 mm × 118 mm (8.5" × 4.8" × 4.7")
|
|
Camera
Weight
|
Approx.
430 g (0.9 lb.)
|
|
With
Package Weight
|
Approx.
634 g (1.4 lb.)
|
|
Protection
|
IP67
(IEC 60529-2013)
|
