Recording
|
|
Video compression
|
H.265 Pro+ / H.265 Pro / H.265
/ H.264+ / H.264
|
|
Encoding resolution
|
When 1080p Lite mode is not
enabled:
4 MP lite / 3 MP / 1080p / 720p
/ VGA / WD1 / 4CIF / CIF;
When 1080p Lite mode is
enabled:
4 MP lite / 3 MP / 1080p
lite / 720p lite / VGA / WD1 / 4CIF / CIF
|
|
Frame rate
|
Main stream:
When 1080p Lite mode not
enabled:
For 4 MP stream access:
4 MP lite@15fps; 1080p lite
/ 720p / WD1 / 4CIF / VGA / CIF @ 25fps (P) / 30fps (N)
For 3 MP stream access:
3 MP / 1080p / 720p / VGA /
WD1 / 4CIF / CIF @ 15fps
For 1080p stream access:
1080p/720p@15fps;
For 720p stream access:
720p / VGA / WD1 / 4CIF / CIF
@ 25fps (P) / 30fps (N)
When 1080p Lite mode
enabled:
4 MP lite/3 MP@15fps; 1080p
lite / 720p lite / VGA / WD1 / 4CIF / CIF@25fps (P) / 30fps (N)
|
|
Sub-stream:
WD1 / 4CIF @ 12fps; CIF @ 25fps
(P) / 30fps (N)
|
|
Video bit rate
|
32 Kbps to 6 Mbps
|
|
Dual stream
|
Support
|
|
Stream type
|
Video, Video & Audio
|
|
Audio compression
|
G.711u
|
|
Audio bit rate
|
64 Kbps
|
|
Video
and Audio
|
|
IP video input
|
2-ch (up to 6-ch)
|
|
Up to 6 MP resolution
|
|
Support H.265+ / H.265 / H.264+
/ H.264 IP cameras
|
|
Analog video input
|
4-ch
|
|
BNC interface (1.0 Vp-p, 75
Ω), supporting coaxitron connection
|
|
HDTVI input
|
4 MP, 3 MP, 1080p25,
1080p30, 720p25, 720p30, 720p50, 720p60
*: The 3 MP signal input is
only available for channel 1 of DS-7104HQHI-K1
|
|
AHD input
|
4 MP, 1080p25, 1080p30,
720p25, 720p30
|
|
HDCVI input
|
4 MP, 1080p25, 1080p30,
720p25, 720p30
|
|
CVBS input
|
Support
|
|
VGA output
|
1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
HDMI output
|
1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
Audio input
|
1-ch, RCA (2.0 Vp-p, 1 KΩ)
|
|
Audio output
|
1-ch, RCA (Linear, 1 KΩ)
|
|
Two-way audio
|
1-ch, RCA (2.0 Vp-p, 1 KΩ)
(using the first audio input)
|
|
Synchronous playback
|
4-ch
|
|
Network
|
|
Remote connection
|
32
|
|
Network protocol
|
TCP/IP, PPPoE, DHCP,
Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
|
|
Network interface
|
1, RJ45 10M/100M
self-adaptive Ethernet interface
|
|
Auxiliary
interface
|
|
SATA
|
1 SATA interface
|
|
Capacity
|
Up to 6 TB capacity for
each disk
|
|
USB interface
|
Real panel: 2 × USB 2.0
|
|
Alarm in/out
|
N/A
|
|
General
|
|
Power supply
|
12 VDC
|
|
Consumption (without HDD)
|
≤ 8 W
|
|
Working temperature
|
-10 °C to +55 °C (+14 °F to
+131 °F)
|
|
Working humidity
|
10% to 90%
|
|
Dimension (W × D × H)
|
200 × 200 × 45 mm (7.9 ×
7.9 × 1.8 inch)
|
|
Weight (without HDD)
|
≤ 1 kg (2.2 lb)
|
