Facial Recognition
|
|
Face Picture Library
|
Up to 16 face picture libraries, with up to 500 face
pictures in total
(each picture ≤ 1 MB,
total capacity ≤ 80 MB)
|
|
Face Picture Comparison (Captured from Camera)
|
Face picture
comparison, face
picture search (1-ch face picture comparison alarm for HD analog camera)
|
|
Motion Detection 2.0
|
|
Human/Vehicle
Analysis
|
Deep learning-based motion
detection 2.0 is enabled by default for all analog channels, it can classify human
and vehicle, and extremely
reduce false alarms caused by objects like leaves and lights;
Quick search by object or event type
is supported;
|
|
Perimeter Protection
|
|
Human/Vehicle
Analysis
|
Up to 4-ch
Note:
Face picture comparison, motion
detection 2.0 and perimeter protection cannot be enabled at the same time.
Enable one function will make the other two unavailable.
|
|
Recording
|
|
Video Compression
|
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
|
|
Encoding Resolution
|
When 1080p
Lite mode is not enabled:
3K lite/5 MP lite/4 MP lite/1080p/720p;
When 1080p Lite mode is enabled:
3K lite/5 MP lite/4 MP lite/1080p lite/720p lite
|
|
Video Bitrate
|
32 Kbps
to 6 Mbps
|
|
Dual-stream
|
Support
|
|
Stream Type
|
Video, Video
& Audio
|
|
Audio Compression
|
G.711u
|
|
Audio Bitrate
|
64 Kbps
|
|
Video and Audio
|
|
IP Video
Input
|
2-ch (up to 10-ch)
Enhanced IP mode on:
4-ch (up to 12-ch), each
up to 4 Mbps
Up to 6 MP resolution
Support H.265+ / H.265 / H.264+ / H.264 IP cameras
Note: Enhanced IP mode might be conflicted with smart events (face
picture comparison, motion detection 2.0 and perimeter protection) or other
functions, please refer to
the user manual for details.
|
|
Analog Video
Input
|
8-ch BNC interface (1.0
Vp-p, 75 Ω),
supporting coaxitron connection
|
|
HDTVI Input
|
3K@20 fps, 5 MP@20
fps, 4 MP@30
fps, 4 MP@25
fps,1080p@30 fps, 1080p@25
fps,720p@30 fps, 720p@25
fps
|
|
AHD
Input
|
5 MP@20 fps,4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
|
|
HDCVI Input
|
5 MP@20 fps,4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
|
|
CVBS Input
|
PAL/NTSC
|
|
HDMI Output
|
1-ch, 1920
× 1080/60Hz, 1280
× 1024/60Hz, 1280
× 720/60Hz,
HDMI/VGA simultaneous output
|
|
VGA Output
|
1-ch, 1920
× 1080/60Hz, 1280
× 1024/60Hz, 1280
× 720/60Hz,
HDMI/VGA simultaneous output
|
|
CVBS Output
|
1-ch, BNC (1.0 Vp-p,
75 Ω),
resolution: PAL: 704 × 576, NTSC:
704 × 480
|
|
Audio Input
|
1-ch (up to 8-ch is optional), RCA (2.0 Vp-p,
1 KΩ) 8-ch via coaxial
cable
Note: The number of audio inputs and alarm in/out can be
optional. The tag on the package will describe audio input and alarm in/out
parameters. For example, “4A+8/4ALM” means your device has 4 audio inputs, 8 alarm inputs and 4 alarm outputs.
If your device only has 1 audio input,
the tag may not describe it.
|
|
Audio Output
|
1-ch, RCA (Linear, 1 KΩ)
|
|
Two-Way Audio
|
1-ch, RCA (2.0 Vp-p,
1 KΩ) (using
the first audio
input)
|
|
Synchronous
playback
|
8-ch
|
|
Network
|
|
Remote Connection
|
64
|
|
Total Bandwidth
|
96 Mbps
|
|
Network Protocol
|
TCP/IP,
PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP,
NFS, iSCSI, UPnP™,
HTTPS, ONVIF
|
|
Network Interface
|
1, RJ45
10/100 Mbps self-adaptive Ethernet interface
|
|
Wi-Fi
|
Connectable to Wi-Fi network by Wi-Fi dongle
through USB interface
|
|
Auxiliary Interface
|
|
Serial Interface
|
RS-485 (half-duplex)
|
|
SATA
|
1 SATA
interface, up to 10 TB capacity for
each disk
|
|
Alarm In/Out
|
N/A (optional to support)
|
|
USB Interface
|
Front panel:
1 × USB 2.0;
Rear panel:
1 × USB 2.0
|
|
General
|
|
Power Supply
|
12 VDC,
1.5 A
|
|
Consumption
|
≤ 18 W (without HDD)
|
|
Working Temperature
|
-10 °C to + 55
°C (14 °F to 131 °F)
|
|
Working Humidity
|
10% to
90%
|
|
Dimension (W × D × H)
|
315 × 242 × 45 mm (12.4 × 9.5
× 1.8 inch)
|
|
Weight
|
≤ 1.78 kg (3.9 lb) (without HDD)
|
