LBC3080/01
Steel fire dome for ceiling loudspeakers
Steel | Flame red RAL 3000 | EN54-24 | LBC3090, LHM0606
LBC3080/01
Steel fire dome for ceiling loudspeakers
Steel | Flame red RAL 3000 | EN54-24 | LBC3090, LHM0606
Key specs
- Fits LBC3087/41, LBC3090/01, LBC3090/31, LHM0606/00, LHM0606/10, LHM0626/00
- Ø 147 mm, depth 87 mm, 360 g
- Steel, flame red RAL 3000
- EN54-24, B15 to DIN 4102
- 4 self-tapping screws, 2 grommets supplied
|
Electrical |
|
|
Maximum power |
15 W |
|
Rated power |
10 / 5 / 2.5 W |
|
Sound pressure level at 10 W / 1 W (1kHz, 1 m) |
99 dB / 89 dB (SPL) |
|
Opening angle at 1 kHz / 4 kHz (-6 dB) |
180° / 90° |
|
Effective frequency range (-10 dB) |
130 Hz to 20 kHz |
|
Rated voltage |
100 V |
|
Rated impedance |
1000 ohm |
|
Connection |
5 m 4-wire cable |
|
Mechanical |
|
|
Dimensions (D x L) |
185 x 157 mm (7.3 x 6.2 in) |
|
Weight |
2.5 kg (5.5 lb) |
|
Color |
White (RAL 9010) |
|
Environmental |
|
|
Operating temperature |
-25 ºC to +55 ºC (-13 ºF to +131 ºF) |
|
Storage temperature |
-40 ºC to +70 ºC (-40 ºF to +158 ºF) |
|
Relative humidity |
<95% |
Know before you buy
Quick answers about the LBC3080/01, and how it compares.
Which fire dome or back box fits my ceiling loudspeaker?
- LBC3080/01: steel fire dome, flame red RAL 3000, EN54-24 certified, for LBC3090/01, LBC3090/31, LHM0606/10, LHM0606/00, LHM0626/00 and LBC3087/41. A white version, LBC3080/11, is available (ask us).
- LBC3081/02: steel fire dome, flame red, for LBC3086/41. With it, the LBC3086/41 is EN54-24 certified.
- LC3-CBB: ABS back box for the LC3 range. The LC3-UC06E is EN54-24 only with it.
- LC1-MFDS metal fire dome, LC1-CMR mounting ring with LC1-CBB back box, or LC1-MMSB bracket: housings for the LC1 range.
The LC3-UM06E and the new Mid and Performance Level models have a metal fire dome built in.
Who supplies Bosch loudspeakers in Pakistan, and what warranty do I get?
Electronic Security Company (ESCO) is the only authorized distributor of Bosch, Dynacord and Electro-Voice in Pakistan, so every Bosch loudspeaker is genuine and comes with a 3-year warranty. Warranty is carry-in: bring the unit to an ESCO office and after inspection it is repaired or replaced as needed.
We supply, design and install public address and voice alarm systems, with offices and stock in Karachi, Lahore, Islamabad and Rawalpindi and dealers across Pakistan.
