LB8-UM06E
Square metal cabinet loudspeaker, 6W
6 / 3 / 1.5 W | Metal enclosure | 93 dB SPL (1W, 1m) | 210 Hz to 18 kHz | EN54-24
LB8-UM06E
Square metal cabinet loudspeaker, 6W
6 / 3 / 1.5 W | Metal enclosure | 93 dB SPL (1W, 1m) | 210 Hz to 18 kHz | EN54-24
Bosch LB8-UM06E Product Highlights
Explore the key capabilities of the Bosch LB8-UM06E cabinet loudspeaker.
EN54-24 Voice Alarm
EN54-24 and BS 5839-8; the line stays up if the speaker burns.
Robust Metal
A square metal enclosure, 175 x 175 mm.
Speech and Music
93 dB at 1 W, up to 101 dB.
Wide Coverage
185° at 1 kHz, 116° at 4 kHz.
Loop-Through
Ceramic terminal with earth, knock-outs for two glands.
Fits Wall Boxes
Mounting holes for U40/50 and MK installation boxes.
Key specs
- Taps 6 / 3 / 1.5 W (100 V), max 9 W
- 93 dB SPL at 1 W, max 101 dB (1 kHz, 1 m)
- 210 Hz to 18 kHz (-10 dB)
- Coverage 185° at 1 kHz, 116° at 4 kHz
- 175 x 175 x 70 mm, 1.64 kg
- Metal enclosure, 4-inch driver
- 3-pole ceramic terminal, thermal fuse, loop-through
- Surface mounting, fits U40/50 and MK boxes
- IP21C
- White RAL 9003
- EN54-24, BS 5839-8
Electrical | |
Rated power | 6 / 3 / 1.5 / 0.75 W |
Sound pressure level at 6 W / 1 W (1 m) | 99 dB / 91 dB (SPL) |
Effective frequency range | 145 Hz to 18 kHz (-10 dB) |
Opening angle | 1 kHz / 4 kHz (-6 dB) |
horizontal | 168º / 89º |
vertical | 168º / 89º |
Rated input voltage | 100 V |
Rated impedance | 1667 ohm |
Connector | 4-pole screw terminal block |
Mechanical | |
Dimensions (H x W x D) | 205 mm x 160 mm x 66 mm (7.82 in x 6.07 in x 2.69 in) |
Weight | 0.83 kg (1.83 lb) |
Color LB10-UC06-FD | Black (RAL 9004) |
Color LB10-UC06-FL | White (RAL 9003) |
Environmental | |
Operating temperature | -25 ºC to +55ºC (-13 ºF to +131 ºF) |
Storage and transport temperature | -40 ºC to +70 ºC (-40 ºF to +158 ºF) |
Relative humidity | <95% |
Know before you buy
Quick answers about the LB8-UM06E, and how it compares.
Which cabinet loudspeaker do I need?
| Model | Power | Build | SPL 1 W, 1 m | Frequency range | Use |
|---|---|---|---|---|---|
| LB1-UW06-FD1 / LB1-UW06-FL1 | 6 W | MDF, cloth front | 91 dB | 185 Hz to 17 kHz | Indoor |
| LB1-CW06-D1 / LB1-CW06-L1 | 6 W | MDF corner cabinet | 91 dB | 180 Hz to 20 kHz | Indoor corners |
| LB10-UC06-FL | 6 W | Flat ABS | 91 dB | 145 Hz to 18 kHz | Indoor |
| LB10-UC06-L / LB10-UC06V-L | 6 W | ABS, angled front; V with volume control | 91 dB | 145 Hz to 18 kHz | Indoor |
| LB7-UC06E | 6 W | ABS, metal grille, EN54-24 | 93 dB | 170 Hz to 20 kHz | Voice alarm |
| LB8-UM06E | 6 W | Square metal, EN54-24 | 93 dB | 210 Hz to 18 kHz | Voice alarm |
| LB1-BW12-D1 / LB1-BW12-L1 | 12 W | MDF, bidirectional | 86 dB | 140 Hz to 20 kHz | Corridors |
| LB2-UC15-D1 / LB2-UC15-L1 | 15 W | ABS, aluminium grille, IP65 | 87 dB | 95 Hz to 20 kHz | Indoor and outdoor |
| LB2-UC30-D1 / LB2-UC30-L1 | 30 W | ABS, aluminium grille, IP65 | 90 dB | 100 Hz to 19 kHz | Indoor and outdoor |
| LB1-UM20E-D / LB1-UM20E-L | 20 W | Aluminium, IP65, EN54-24 | 88 dB | 90 Hz to 20 kHz | Indoor, outdoor, voice alarm |
| LB1-UM50E-L | 50 W | Aluminium, IP65, EN54-24 | 91 dB | 90 Hz to 20 kHz | Indoor, outdoor, voice alarm |
Codes ending D are black or charcoal, L are white. For evacuation systems pick the EN54-24 LB1-UM models.
What does EN54-24 mean?
EN 54-24 is the European standard for loudspeakers in voice alarm (evacuation) systems. Certified models show EN54-24 in the banner at the top of their page; the others show Non-EN54 and suit commercial public address and music. For an evacuation system, use EN54-24 loudspeakers throughout.
What do the power taps mean?
Each loudspeaker can be set to one of its power taps, for example 6 / 3 W. Choose a lower tap for small or quiet areas and a higher tap for large or noisy ones. Add up the taps of every loudspeaker on a line: the amplifier must deliver at least that total.
Many 6 W ceiling loudspeakers are tapped down to 3 W, 1.5 W or 0.75 W in the field; in smaller or low-noise areas 3 W is more than enough.
Who supplies Bosch loudspeakers in Pakistan, and what warranty do I get?
Electronic Security Company (ESCO) is the only authorized distributor of Bosch, Dynacord and Electro-Voice in Pakistan, so every Bosch loudspeaker is genuine and comes with a 3-year warranty. Warranty is carry-in: bring the unit to an ESCO office and after inspection it is repaired or replaced as needed.
We supply, design and install public address and voice alarm systems, with offices and stock in Karachi, Lahore, Islamabad and Rawalpindi and dealers across Pakistan.
