LB2-UC30-D1
Premium-sound cabinet loudspeaker, charcoal, 30W
30 / 15 / 7.5 / 3.75 W | ABS, aluminium grille | 90 dB SPL (1W, 1m) | 100 Hz to 19 kHz | Non-EN54
LB2-UC30-D1
Premium-sound cabinet loudspeaker, charcoal, 30W
30 / 15 / 7.5 / 3.75 W | ABS, aluminium grille | 90 dB SPL (1W, 1m) | 100 Hz to 19 kHz | Non-EN54
Bosch LB2-UC30-D1 Product Highlights
Explore the key capabilities of the Bosch LB2-UC30-D1 cabinet loudspeaker.
Premium Two-Way Sound
5-inch woofer, 13 mm dome tweeter: 90 dB at 1 W, up to 105 dB.
IP65, Pool and Coast
IP65, resistant to chlorine, corrosion and salt mist.
8 Ohm, 70 V or 100 V
A switch on the back selects the input and taps 30 / 15 / 7.5 / 3.75 W.
Anti-Theft Bracket
Adjustable U-bracket with torx screws under matching covers.
Mount Any Way
Horizontal or vertical; the logo rotates to match.
Bars to Boardrooms
Theme bars, restaurants, retail, offices, showrooms and fitness centres.
Key specs
- Taps 30 / 15 / 7.5 / 3.75 W (70 / 100 V), 8 ohm
- Max 45.0 W
- 105 / 90 dB SPL at rated / 1 W (1 kHz, 1 m)
- 100 Hz to 19 kHz (-10 dB)
- Opening angle 166° / 83° H, 140° / 76° V (1 / 4 kHz)
- 5-inch woofer, 13 mm dome tweeter
- 250 x 160 x 140 mm, 2.4 kg
- ABS enclosure, aluminium grille
- Fixed 2 m two-core cable
- IP65; chlorine, corrosion and salt mist resistant
- Charcoal RAL 7021
- Not EN54-24
|
Electrical |
|
|
Maximum power |
22.5 W |
|
Rated power (PHC) |
15 W |
|
Power tapping |
15/7.5/3.75/1.9 W |
|
Sound pressure level at rated power / 1 W (1 kHz, 1 m) |
99/87 dB (SPL) |
|
Effective frequency range(-10dB) |
95 Hz to 20 kHz |
|
Opening angle at 1 kHz / 4 kHz (-6 dB) |
184° / 112° (hor.) 170° / 35° (ver.) |
|
Rated input voltage |
11/70/100 V |
|
Rated impedance |
8/326/667 ohm |
|
Transducers |
101.6 mm (4”) woofer, 13 mm (0.51 “) dome tweeter |
|
Connection |
2 m (78.8 in.) two‑wire cable |
|
Mechanical |
|
|
Dimensions (HxWxD) |
205 x 136 x 117 mm 8.07 x 5.35 x 4.60 in |
|
Weight |
Approx. 1.9 kg (4.18 lb) |
|
Color |
Charcoal (RAL 7021) (D) |
|
Environment |
|
|
Operating temperature |
-25 ºC to +55 ºC (-13 ºF to +131 ºF) |
|
Storage and transport temperature |
-40 ºC to +70 ºC (-40 ºF to +158 ºF) |
|
Relative humidity |
<95% |
Know before you buy
Quick answers about the LB2-UC30-D1, and how it compares.
Which colours are available?
The same loudspeaker in two colours: LB2-UC30-D1 in charcoal or black and LB2-UC30-L1 in white.
Which cabinet loudspeaker do I need?
| Model | Power | Build | SPL 1 W, 1 m | Frequency range | Use |
|---|---|---|---|---|---|
| LB1-UW06-FD1 / LB1-UW06-FL1 | 6 W | MDF, cloth front | 91 dB | 185 Hz to 17 kHz | Indoor |
| LB1-CW06-D1 / LB1-CW06-L1 | 6 W | MDF corner cabinet | 91 dB | 180 Hz to 20 kHz | Indoor corners |
| LB10-UC06-FL | 6 W | Flat ABS | 91 dB | 145 Hz to 18 kHz | Indoor |
| LB10-UC06-L / LB10-UC06V-L | 6 W | ABS, angled front; V with volume control | 91 dB | 145 Hz to 18 kHz | Indoor |
| LB7-UC06E | 6 W | ABS, metal grille, EN54-24 | 93 dB | 170 Hz to 20 kHz | Voice alarm |
| LB8-UM06E | 6 W | Square metal, EN54-24 | 93 dB | 210 Hz to 18 kHz | Voice alarm |
| LB1-BW12-D1 / LB1-BW12-L1 | 12 W | MDF, bidirectional | 86 dB | 140 Hz to 20 kHz | Corridors |
| LB2-UC15-D1 / LB2-UC15-L1 | 15 W | ABS, aluminium grille, IP65 | 87 dB | 95 Hz to 20 kHz | Indoor and outdoor |
| LB2-UC30-D1 / LB2-UC30-L1 | 30 W | ABS, aluminium grille, IP65 | 90 dB | 100 Hz to 19 kHz | Indoor and outdoor |
| LB1-UM20E-D / LB1-UM20E-L | 20 W | Aluminium, IP65, EN54-24 | 88 dB | 90 Hz to 20 kHz | Indoor, outdoor, voice alarm |
| LB1-UM50E-L | 50 W | Aluminium, IP65, EN54-24 | 91 dB | 90 Hz to 20 kHz | Indoor, outdoor, voice alarm |
Codes ending D are black or charcoal, L are white. For evacuation systems pick the EN54-24 LB1-UM models.
What do the power taps mean?
Each loudspeaker can be set to one of its power taps, for example 6 / 3 W. Choose a lower tap for small or quiet areas and a higher tap for large or noisy ones. Add up the taps of every loudspeaker on a line: the amplifier must deliver at least that total.
Many 6 W ceiling loudspeakers are tapped down to 3 W, 1.5 W or 0.75 W in the field; in smaller or low-noise areas 3 W is more than enough.
Can I get the loudspeakers in a custom colour?
Yes. Bosch paints loudspeakers in any RAL colour to blend in with the architecture of hotels, malls, airports and similar projects. The paint is durable, suits indoor and outdoor use, keeps the EN54 certification and has a 3-year warranty. Tell us the models, quantities and RAL code.
Who supplies Bosch loudspeakers in Pakistan, and what warranty do I get?
Electronic Security Company (ESCO) is the only authorized distributor of Bosch, Dynacord and Electro-Voice in Pakistan, so every Bosch loudspeaker is genuine and comes with a 3-year warranty. Warranty is carry-in: bring the unit to an ESCO office and after inspection it is repaired or replaced as needed.
